Series 52-10-182
2/2-way economy brass solenoid valves type 52 as poppet seat valves. With a small nominal width, high pressures can be switched with relatively small and low-power solenoids, which is why the series is mainly used in G1/8 and G1/4 with nominal widths DN1.0 to DN2.5 mm.
Technical informations
Connections
G1/8, G1/4
Pressure
0 bar up to 50 bar
Temperature
-10 °C up to 80 °C
Type of Control
electr. direct
Housing materials
CW617N brass
Sealing
FKM
Media
Fuel Oil, Gasoline, Dieseloil, Fuels, Additives for Fuels, Marine Gas Oil (MGO), Water, H2O, Air, Argon Ar, Gases flammable, JP-8 jet fuel aviation, kerosine, Methane CH4, Nitrogen Gas N2, CO carbon monoxide, CO2 carbon dioxide gas, Motor Oil, Mineral Oil, Propane/Butane gaseous C3H8, LPG liquified petrol gas propane, butane, Hydraulic Oil, natural Gas CH4, Ethylene C2H4, Propylene, Propene - C3H6, propylene glycol C3H8O2, neongas NE, Ethane C2H6, Helium Gas He, heptane ( hexan, petrol), Oxygen O2
