B4858-A4868/0809

Seat Valve electr. direct

Series 48-0809

Valve B4848/0809/1012-NG DC

The solenoid valve for gas odors such as s-free, THT, mercaptan is normally closed in the rest position by spring force (NC). Valves of this type do not require a differential pressure (∆p). The valves are gas tightly sealed due to the FFKM sealing material.

For more information follow this link:

Valve B4848/0809/1012-NG DC

Datasheet explicit

Datasheet universal

datasheet (PDF) 48 FFKM

Instructions

Manual direct operated valves

Solenoid coil .012

Others

EC Declaration of Conformity

REACH Declaration

RoHS Declaration

STEP Files

048.001295_B4868-0802-.148.stp

Version	B
Type of valve	48	Seat Valve electr. direct
Connection type, valve seat	48	G1/4 8mm
Kv-value (Δp = 1 bar H₂O)
Housing	08	AISI 316 Ti - 1.4571(81)
Sealing	09	FFKM
Voltage type	1	DC
Solenoid power	01	18,5W/24VA
Protection class	2	IP65
Valve option	NG	normally closed + Valve body with NPT thread
Pressure rating		PN40
System pressure		0 - 3 bar
Valve type		12V, 24V, 48V, 110V, 120V, 220V, 230V, DC
Temperature Medium		from -15 °C to 90 °C
Temperature Environment		from -15 °C to 40 °C
Mounting position		Pipeline horizontal, Actuator vertical up
Specific use case		Closed system (includes open system)
scope of delivery		1 valve, 1 connector FormA EN175301-803/A \| max. current 10A \| 4x90°\| IP65 when installed \| connectable cables Ø 5-10 mm max.1.5mm² \| 1 Solenoid .012 K05101XX \| 100% duty cycle \| rotatable 360° \| Valve MatchCode G0xx.xxxxxx.0xx.009.0xx \|

Valve option	NG	normally closed + Valve body with NPT thread
Description		Valve opens with continuous voltage \| Conical internal thread
Leakage rate		A - EN 12266 [Test medium air or nitrogen, 20°C room temperature]
REACH-RoHS conformity		REACH Yes \| RoHS Yes
Customs export		Customs tariff number 84818073; Country of origin Germany; ECCN (US): N; AL: N

Not applicable
